Technical Data Sheet

Engine & Performance

• Engine Type: Single-cylinder, 4-stroke, 2-valve

• Displacement: 124.6 cm³

• Valve Train: SOHC (single overhead camshaft)

• Bore × Stroke: 52.4 × 57.8 mm

• Compression Ratio: 9.2 : 1

• Cooling System: Air-cooled

• Fuel System: Electronic fuel injection (EFI)

• Emission Standard: Euro 5

• Maximum Power: approx. 9.7 hp (≈ 7.1 kW) at 7,000 rpm

• Maximum Torque: 8.5 Nm at 6,000 rpm

• Ignition: Electronic (TCI)

• Starter: Electric

Transmission & Drivetrain

• Gearbox: Automatic

• Transmission Type: CVT (continuously variable transmission / variator)

• Clutch: Automatic, centrifugal

Performance & Consumption

• Top Speed (realistic): around 80–85 km/h

• Fuel Consumption (typical): about 2.5–3.0 L/100 km (urban/mixed use)

• CO₂ Emissions: around 61 g/km

Chassis & Suspension

• Frame Type: Tubular steel underbone-type frame

• Front Suspension: Conventional telescopic fork

• Rear Suspension: Single rear shock absorber (engine-swingarm with lateral mono-shock)

Brakes & Wheels

• Front Brake Type: Disc brake, single-piston caliper

• Front Disc Diameter: approx. 220 mm

• Rear Brake Type: Disc brake

• Braking System: CBS (Combined Braking System)

• Rim Type: Cast alloy rims

• Front Rim Size: 12″

• Rear Rim Size: 12″

• Front Tyre Size: 110/70–12

• Rear Tyre Size: 120/70–12

Dimensions & Weight

• Overall Length: approx. 1,920–1,950 mm

• Overall Width: 680 mm

• Overall Height: 1,180 mm

• Wheelbase: 1,360 mm

• Seat Height: 790 mm

• Kerb Weight (ready to ride): approx. 110 kg

• Fuel Tank Capacity: approx. 5.6–6.0 litres

Equipment

• Lighting: Full LED (headlight, tail light, and indicators)

• Instrument Panel: Digital LCD display (speedometer, odometer, fuel gauge, etc.)

• Key System: Keyless / remote control (on recent Euro 5 versions)

• Underseat Storage: Space for one jet helmet + small extra compartment

• Floor: Flat floor with bag hook on the leg shield

• Seat: Two-up bench seat, brown/cream tone, with grab rail and rear rack

Colours Available

• Grey

• Black

• Red

Warranty

• 5 years or 30,000 km
